seems the newer bigger hlgs- Cs lose a little bit in efficiency compared to the 185s,120s.
good to keep in mind when designing a light.
HLG-320H-C3500 drivers out in april
- Thread starter BOBBY_G
- Start date
good to keep in mind when designing a light.
Fastslappy
Well-Known Member
Bobby
so what # of cobs & watts per cob , configuration would u run off that single puppy ?
just trying to twist my mind to the #'s on the new stuff
BOBBY_G
Well-Known Member
my MO is to come in hot with less cobs at 50% efficiency (oh so horrible right, lol), and expand out to a more efficient array after first crop
phase 1 ($2200):
5x9 tent
3x HLG-600H drivers
24 cobs@ 2.1A, 75W per cob
~900 PPFD depending on bin (8x 3000k BD, 8x3500k CD, 8x 4000k DB)
1800W at wall
(6) 4.85" x 48" heatsinkusa active heatsinks, 4 cobs per (sized for future passive utility)
future: evaluate the 3 bins above and build out tent efficiency by adding cobs based on the results. so lets just say i find my magic bin/color temp and go with it
phase 2 ($2000 more):
same tent, same 3 drivers, same 6 heatsinks and add 36 more cobs and 4 more heatsinks and do 6 cobs per heatsink
60 cobs
max mode (1120 ppfd): 0.9A/30W per cob @ 62% eff
normal mode (880 ppfd): 0.7A/23W per cob @ 64.4% eff
key points:
-600W driver has a low inrush current (70A) relative to the HLG-185 series (55A each) and reduces ancillary electrical equipment
-600W driver is most efficient in class, 96% across the board from 50-100% load
-high current driver lets me run at any current i want, as ill prob change my mind 6x in the future
-not a woman and 17A@36V doesnt scare me
Last edited:
BOBBY_G
Well-Known Member
yes i mean the 2800 model. 3500 is a benchmark but an anomaly in our 36V cob world. it can run [email protected] at 84% load on that driver
obviously the 3 @ 2800ma using 98% of the driver is better
Airwalker16
Well-Known Member
Meanwell emailed me a few days back and told me the first of May. Remains to be seen though. PAIRUI drivers that cutter supplies has a 250 version with amperages STARTING at 1400 and goes all the way to 4200. If you want high currents, you don't need to wait.
Last edited:
Vescovi
Active Member
So Greengenes707, now I am lost. Bobby said 42V, For this 3 COB bar 36V @ 2.8 what driver should i get? 36 or 42V? Keeping in mind I am looking for a single driver per bar.
The 3 COB 300W-ish and the 2 COB 200W-ish.
JEEZ,
Sorry, Thanks mate
Airwalker16
Well-Known Member
Are you running in series or parralel? That's your deciding factor. Go with series
The Dawg
Well-Known Member
I Stand Corrected The Rating For The MW And Inventronics Are 92% @120 And 94% @240
P.S. Either Get Glasses or Put The Jack Rag Away
Vescovi
Active Member
green217
Well-Known Member
I like it man, damn i wish i had the $ to put up to build half that first light for my flower room.
Rahz
Well-Known Member
It's disappointing, but the 240 preliminary data was revised before release so perhaps they will make some improvements before the 320 comes out.
BOBBY_G
Well-Known Member
looks like the new datasheet is much better, 94% at 230V
www.rollitup.org/attachments/meanwell_hlg-320h-c-led_driver_datasheet-pdf.3621997/
www.rollitup.org/attachments/meanwell_hlg-320h-c-led_driver_datasheet-pdf.3621997/
jewbag
Well-Known Member
Fastslappy
Well-Known Member
what do they cost ?
giantsfan24
Well-Known Member
It looks to me, and I could be wrong, that one 320-1400 would run 6, 36v cob's? s my math-ish correct?
